HIGH PRESSURE AXIAL PISTON PUMPS
Home – HIGH PRESSURE AXIAL PISTON PUMPS
Six hardened steel pistons located in a stationary body are not subject to centrifugal force, thus reducing load and wear. The piston load is caused by pumping action only, therefore higher operating speeds are possible.
Hardened steel for hard on hard wear resistance
- Hydrostatically
balanced design reduces
piston shoe load and
provides lubrication for increased life. - Facilitates a high degree
of contamination wear
resistance - Permits higher pressure
operation with long life - Allows operation with
low viscosity or other
special fluids including
95/5. Consult Oilgear for
more information.
Hardened steel for hard on hard wear resistance
A through drive is provided for tandem mounting other equipment
Built-in gear pump supercharges, lubricates and provides case flow for cooling the main pump.
These axial piston pumps are used in a wide variety of applications, including die casting and injection molding machines, high pressure test rigs, civil and marine projects, intensifier system, extrusion presses and high pressure forced lubrication systems for long turbines as well as metal forming machines. The Pump has proved itself successful for use with high water content low viscosity fluids.
- Inlet and delivery check
valves are positive seated
for high volumetric
efficiency - Rugged, high response,
lightweight poppet
construction assures
long life
